Mechanical Press HCP-500 500 Tons
MachEx ID
MX202300086
Category
Metal Forming Machinery
Type
Hot Forging Press
Brand
JING DUANN
Model
HCP-500
Accessories
Specification
500 Tons
Years
2000
Location
Taiwan
Conditions
Reconditioned
Power
220V 60HZ 3PH
Description
Capacity: 500 Ton Stroke of ram: 150 mm Adjustment of ram: 50 mm Number of Stroke: 85 spm Work number of stroke: 16 spm Shut Height: 510 mm Rated tonnage point: 5mm Rated Dimension: 670x600 mm Table Dimension (LRxFB): 770x1100 mm Side window(LRxFB): 400x370 mm Main Motor: 37kw x 6p Ejector in the ram: 3Ton - 20mm Ejector in the table: 5Ton - 40mm Machine Weight: 32,000 kgs Machine Dimension(LxWxH): 2829x2490x4310 mm
Interface
Chinese ＆ English
